Easy Steps to Connect Multiple Public IPs to a Single Amazon EC2 Server
Introduction to AWS Elastic IP
Elastic IP (EIP) addresses are more like static IPv4 addresses suitable for cloud computing. The main goal of these IPs is to hide any software or instance failures from your AWS account. This is accomplished by remapping the address to another instance that is as soon as possible available in your account. Your AWS account is automatically assigned an IP address, which remains yours until you wish to surrender it. However, you can specify the IP in a DNS record for your domain. It ensures that the provided domain directs traffic to your instance.
Like any other public IPv4 address, this address can be accessed over the internet. If your instance does not have a public IPv4 address, you can associate this IP address with it to allow communication from the internet to the instance. Currently, the AWS EIP does not support IPv6 addresses.
Difference between Elastic IP, Public IP, and Static IP
Your public IP address is how the internet recognizes you. Your internet-connected device’s public IP address is the address it uses to communicate with the rest of the internet. Static IP addresses are IP addresses that do not change. They’re common in business and cloud computing, which is why they are included in Amazon’s Elastic IP framework. For a variety of reasons, a static IP address is advantageous. A static IP address is helpful for DNS queries in cloud computing. If IP addresses change, the process of loading content may be impeded.
According to AWS, Elastic IP is used for dynamic cloud computing in the AWS cloud environment. Understanding the difference is critical because if your AWS instance goes down, you’ll need to keep your IP address and maintain contact with your account.
As a result, an Elastic IP address is a cross between a public and a static IP address. It allows you to continue advertising AWS instances throughout your AWS network infrastructure.
AWS EC2 servers: – AWS EC2 is a web service that offers on-demand scalable compute capacity on a pay-per-use basis. EC2 is built on server virtualization, which allows an essentially limitless number of computers with nearly limitless capacity. As AWS customers, we refer to these machines as “instances.” Users can dynamically build, work, and grow EC2 instances according to their needs.
There are specific requirements where there is a need to add multiple public IP addresses to a single EC2 server in AWS. In this blog, we will understand simple steps to achieve this requirement.
Steps to connect multiple public IPs to a single EC2 server
Step 1 – Create an EC2 instance (Amazon Linux 2) and also allocate two elastic IPs
Step 2 – Select your EC2 server, click on Actions>>Networking>>Manage IP addresses
Step 3 – Add one more Private Ip and then click on Save.
Step 4 – Go to elastic IPs and select EIP-1. Click Actions>> Associate Elastic IP address. Select the EC2 server, select a private Ip from the dropdown, and then click Associate. Repeat the same steps for EIP-2
Step 5 – Go to your EC2 server console and you can see that both the elastic IPs are successfully associated
Step 6 – Now SSH into your server and run the following command “ip addr li” to check the associated private IPs, you can see only one private IP is associated for now
Step 7 – So to solve this, we must run a command to refresh the network “sudo service network restart “, once restarted run “ip addr li” command again and confirm if 2 private IPs are propagating or not
Conclusion
We can conclude that more than one public IP can be attached to the EC2 server, for which we also need more private IPs to the server, and public IPs can be mapped with the private IPs easily, as shown above. Once Elastic IPs are successfully attached, you can easily use them to access your server. Also, this can be configured in Windows and other OS types; you just need to configure and map the private IPs in the server.
About CloudThat
CloudThat is the official AWS (Amazon Web Services) Advanced Consulting Partner, Microsoft Gold Partner, Google Cloud Partner, and Training Partner helping people develop knowledge of the cloud and help their businesses aim for higher goals using best-in-industry cloud computing practices and expertise. We are on a mission to build a robust cloud computing ecosystem by disseminating knowledge on technological intricacies within the cloud space. Explore our consulting here.
If you have any queries regarding AWS EC2 server integration, public, private or hybrid cloud, or any other query regarding cloud services, drop a line in the below comments section. I will get back to you at the earliest.
FAQs
-
Can this be done with all OS types?
Yes. We need to configure and map the private IPs in the server.
-
Can associate Elastic IPs easily be disassociated?
Yes, they can be disassociated and deallocated easily.
