Leverage AWS S3, Lambda & SNS to Setup Event-driven Messaging Service

November 14, 2022 | Comments(0) |

TABLE OF CONTENT

1. Introduction
2. Prerequisites
3. Architecture Diagram
4. Step-by-Step Guide for Event-Driven Messaging Service
5. Conclusion
6. About CloudThat
7. FAQs



Introduction

Broadcasting messages to an extensive use group is time-consuming and requires immense effort when performed manually. AWS provides various services that can be leveraged to set up event-driven messaging.

This blog combines S3 Bucket, Lambda, and SNS topics. Any S3 bucket upload, update or remove event will start an AWS Lambda function. After retrieving the file details, a lambda function will cause an AWS SNS topic to deliver email notifications to the subscribers with the file details.

To send emails to the subscribers, we will develop a lambda function that will take events from an S3 bucket and then trigger SNS topics. When a file is uploaded, updated, or removed from an S3 bucket, the AWS lambda function should be triggered to retrieve the file’s information and start an AWS SNS topic that will send email notifications to the topic’s subscribers.

Prerequisites

  • AWS account
  • AWS IAM permissions for required Services
  • AWS CLI

Architecture Diagram

The architecture diagram above shows how an event is triggered from S3, captured by a lambda function, and then passed to Amazon SNS, which sends emails to the customers.

Step-by-Step Guide for Event-Driven Messaging Service

Summary

  1. First, create an S3 bucket
  2. Create an SNS subscription and confirm the email subscription
  3. Create a policy and role
  4. Create a Lambda Function

Step I: Creating Amazon S3 bucket

Step 1: Sign into the AWS console and search for S3 in the search bar and select the service

Step 2: Click on Create bucket

Step 3: Give the bucket information as follows:

  • Give the bucket a suitable name (the name must be globally unique)
  • Choose a region,
  • Enable the public ACL, and
  • Next, click on create a bucket

Step 4: As soon as a bucket is created, it appears on the list of buckets. To see additional information, select the bucket.

AWS SNS

Step II: Creating the topic:

Step 1: Sign into the AWS console and search for Simple Notification Service (SNS) in the search bar and select the service

Step 2: Provide the proper name of the topic and click on create next step

AWS SNS

Step 3: The steps mentioned below will help in creating the topic

  • Select the type as standard
  • The topic’s name will be presented as specified in the previous step
  • The remaining steps are optional
  • Click on create a topic

Step 4: The topic is pooped up on top after it has been created. To see additional information, select the created topic.

AWS SNS

Step 5: Create a Subscription

  • Once the topic has been properly created, we must create a subscription for the customer to receive emails.
  • Select “create a subscription,” and the topic name will appear
  • From the selection, choose the HTTP protocol
  • Substitute a valid email-id for the endpoint
  • Click on create a subscription.

Step 6: Confirm the subscription

  • When the subscription is made, the status will show as “waiting for confirmation.”
  • The confirmation email will be sent to the email address provided in the previous stage when subscribing to the topic.
  • Click the “click here to subscribe” link in the email to complete the subscription process
    AWS SNS
  • After the mail confirmation, we can see the subscription status as confirmed.
    AWS SNS

Step III: Creating IAM Role:

  • An IAM role needs to be created for lambda execution. The actions listed below will assist in creating a role.
  • Start up the IAM console.
  1. In the left navigation pane, select role.
  2. Select Create Role.
  3. Select Lambda as the everyday use case and the trusted entity type as an AWS service.
  4. Select Next, go to the Add Permissions page, and select Create Policy.
  5. The page for creating policies to access AWS resources appears in a new tab.
  6. Enter the name of your choice and select Create Policy on the review page.
  7. Select the newly generated policy and attach the authorization policy page.
  8. Choose a name for the role on the name, review, and create the page.

AWS SNS

AWS SNS

AWS SNS

Step IV: Creating the Lambda function:

Step 1: Create a lambda Function to trigger the upload event in S3 Bucket.

  • Choose the Author from scratch.
  • Provide the name of the function.
  • In the position of runtime, we must choose the language that we want. Here, I am choosing the most recent Python version.
  • Choose whether to create a new or existing role as the executing role in the following step. I’m choosing the role that I already created in the previous phase.
  • Rest everything. We can keep it optional
  • Select Create a Function.

AWS SNS

Step 2: Adding triggers to the lambda function:

  • Choose an S3 bucket as the source.
  • Next, choose the bucket we want to add as a trigger.
  • The remaining steps are optional.
  • Click on Add

Step 3: Add the SNS destination to the Lambda

  • The final step is to add a destination.
  • Choose Asynchronous invocation for the source.
  • Choose On Success for the condition
  • Choose SNS Topic for the destination type
  • And the topic we defined in the previous phase.
  • Click on add.

AWS SNS

Result:

Lambda is triggered when the image is uploaded to the S3 bucket and sends the SNS notification.

AWS SNS

Conclusion

We can conclude how to cause Lambda to run asynchronously when new S3 bucket events (uploads, deletions, and updates) occur. Additionally, we have understood how to establish SNS as a destination in the lambda function so that the email notification is sent to every subscriber. Because of this, monitoring the S3 bucket to observe what events are happening is made more accessible by this idea.

About CloudThat

CloudThat is the official AWS (Amazon Web Services) Advanced Consulting Partner, Microsoft Gold Partner, Google Cloud Partner, and Training Partner helping people develop knowledge of the cloud and help their businesses aim for higher goals using best-in-industry cloud computing practices and expertise. We are on a mission to build a robust cloud computing ecosystem by disseminating knowledge on technological intricacies within the cloud space. Our blogs, webinars, case studies, and white papers enable all the stakeholders in the cloud computing sphere.

If you have any queries about the Event-driven Messaging Service, AWS Lambda, or any other AWS service, drop them in the comment section and I will get back to you quickly.

CloudThat is a house of All-Encompassing IT Services on the cloud offering Multi-cloud Security & Compliance, Cloud Enablement Services, Cloud-Native Application Development, and System Integration Services. Explore our consulting here.

FAQs

  1. Why should I use Lambda?

Code execution in reaction to events, such as modifications to an Amazon S3 bucket, is made simple by AWS lambda. AWS Lambda handles all the operational and administrative tasks on your behalf, enabling quick code refactoring and high availability without further effort.

  1. What is the role of SNS in this blog?

Amazon Simple Notification Service (SNS) is used to notify subscribers when the event is triggered in S3 Bucket.
